SKU: AZVS15ECXWA

Dimensions: 16 H x 42 W x 20.8125 D

Color: Grey White

Cooling BTU: 15,000 BTU

Voltage: 265 Volt

Images are for reference only. Please verify the model number and written specifications on your quote or order confirmation. Ordering information

About This Product

Designed & Assembled in America

Date of Manufacture – 2025 or later

Eco-Friendly Build
Zoneline® Perfect Control units use the most environmentally friendly refrigerants currently offered in PTAC's, helping commercial building meet LEED standards and reduce their environmental footprint
Inverter Technology
Variable speed operation provides an advantage with shorter recovery time, improved efficiency, sound quality and dehumidification
Efficient cold weather heat pump
Advanced defrost capability allows for extended heat pump down to 0°F
New Upgraded Appearance
New grey white chassis color will compliment any installation and room décor. Easy-to-read interface makes navigation simple.
Whisper Quiet Operation
Large cross-flow blower, a variable speed compressor and two EC motors work together to minimize noise and maximize comfort.
Industry Leading Performance
Perfect Control technology senses temperature and humidity onboard the unit and occupancy via optional wall thermostats. Proprietary heat load algorithms sense room size to automatically adjust output and target comfortable humidity levels.
Best-In-Class Reliability
With over 1 million units installed, Zoneline® PTACs offer unrivaled reliability backed by a dedicated service network and field team that helps you stay up and running
Unmatched Durability
All Zoneline® units are made of the highest quality material and tested in extreme environments to ensure they operate at peak performance, season after season

Specs & Details

Dimensions: 16 H x 42 W x 20.8125 D

Accessories Required for Installation

RAB42 - Wall Case
Outdoor Grille

Color Appearance

Grey White

Central Desk Control Compatibility	Yes
Chassis Type	Slide-In
Control Type	Standard Microcomputer Tactile touch pad with LED Display
Corrosion Treated	Yes
Discharge Grille	2-position
Electronic Micro Computer Control	Yes
Fan Cycle Switch	Yes
Fan Motor	2 EC Controlled
Fan Speed Control	Yes
Fan Speed Selections	Hi/Low Cooling Hi/Low Heating Hi/Low Fan Only
Filter Type	Rigid Frame Slide-Out
Freeze Sentinel	Yes
Heat - Cool	Yes
Heat Pump	Yes
Heat Sentinel	Yes
Heating - Reverse Cycle - COP	3 .4
Heating System	E Heat/High Demand/Hybrid/Boost/HP Only
HSPF2 Rating	7
Louver Style	Reversible
Makeup Air	Yes
Manual Vent Control	Hidden
Power Factor	95
Product Type	Packaged Terminal Air Conditioners (PTAC)
Refrigerant Charge (oz.)	29
Refrigerant Type	R454B
Rotary Compressor	Yes
SEER2	16
Sensible Heat Ratio	0.75
Temperature Limiting	Electronic 24-Step
Temperature Range	60 - 85 F
Vent Control	3-position
Venting Features	Concealed Manual Vent Control Vent Air Filter Outdoor Vent Control - 3 Positions
WiFi Connect	Built-In
Zoneline Features	"Smart Fan" Fan Cycle Control Heat Sentinel Freeze Sentinel Automatic Indoor Frost Control Universal Heaters Auto Power Recovery Remote Thermostat Compatibility Central Desk Control Compatibility Random Twist/Length Segment Tangential Blower

Cooling - Amperes	5.1
Cooling - Watts	1295
Heating BTUH	4,000 - 14,000
Heating - Electric - Heater Amps	4.5
Heating - Electric - Heater Watts	1165
Voltage (MAX)	265 V

Labor Warranty	Limited 1-year entire appliance Limited 5-year sealed system
Parts Warranty	Limited 2-year entire appliance
Warranty Notes	See written warranty for full details
