Summit 2-Drawer All-Refrigerator, ADA Compliant (Panels Not Included), 24" Wide, Black (ASDR2414PNR)
Summit 2-Drawer All-Refrigerator, ADA Compliant (Panels Not Included), 24" Wide, Black (ASDR2414PNR)
SKU: ASDR2414PNR
Dimensions: 32 H x 23.38 W x 17.88 D
About This Product
The Summit ASDR2414PNR is a 24" wide 2-Drawer all-refrigerator, ADA compliant (Panels not Included). It puts refrigerated storage in easy-to-reach pull-out drawers under an island, beside a range or behind a bar. The cabinet measures 32 in. H x 23.38 in. W x 17.88 in. D, offers 3.1 cu.ft. of capacity and uses frost-free defrost.
The black cabinet is paired with a stainless steel/panel-ready door. It operates on 115 V AC/60 Hz and draws 1 amps. It meets ADA height requirements for accessible installations. The door accepts a custom panel (sold separately) for a seamless built-in look. It is backed by a 1-year manufacturer parts and labor warranty.
Planning a multi-unit project? Request a quote and our team will confirm pricing, availability and freight to your site.
Key Features
- 2-Drawer All-Refrigerator
- Panel-ready drawer fronts
- Stainless steel front finish
- Less than 18" deep
- ADA compliant design
- Adjustable height
- Built-in capable
- Stainless steel drawers
- Professional handles
- Frost-free
- Digital thermostat
- Interior lighting
Specs & Details
Dimensions: 32 H x 23.38 W x 17.88 D
OVERVIEW
| Brand | Summit |
| Model | ASDR2414PNR |
| Category | Refrigerator Drawers |
DIMENSIONS
| Nominal Height | 32.0" (81 cm) |
| Height of Cabinet | 32.0" (81 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.38" (59 cm) |
| Nominal Depth | 18.0" (46 cm) |
| Depth | 17.88" (45 cm) |
| Depth with door at 90° | 29.63" (75 cm) |
| Height Adjustable | Yes |
| Interior Height 1 | 8.0" (20 cm) |
| Interior Width 1 | 17.63" (45 cm) |
| Interior Depth 1 | 11.25" (29 cm) |
| Interior Height 2 | 8.0" (20 cm) |
| Interior Width 2 | 17.63" (45 cm) |
| Interior Depth 2 | 11.25" (29 cm) |
| Compressor Step Height | 3.75" (10 cm) |
| Compressor Step Width | 17.63" (45 cm) |
| Compressor Step Depth | 4.75" (12 cm) |
CAPACITY & STORAGE
| Capacity | 3.1 cu.ft. (88 L) |
| Cabinet | Black |
| Interior Light | Yes |
ELECTRICAL
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Energy Usage/Year | 285.0kWh/year |
| Amps | 1.0 |
| Voltage/Frequency | 115 V AC/60 Hz |
COOLING & PERFORMANCE
| Defrost Type | Frost-Free |
| Compressor Warranty | 5 Years |
| Thermostat Type | Digital |
| Fan Type | Interior and Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 1.38oz. |
| High Side PSI | 270.0 |
| Low Side PSI | 105.0 |
| Temperature Range | 36 to 43ºF |
| Sound Level | 33 dB |
CERTIFICATIONS & WARRANTY
| Sanitation | ETL-S |
| Parts & Labor Warranty | 1 Year |
FEATURES & FINISH
| Door | Stainless Steel/Panel-Ready |
| Weight | 106.0 lbs. (48 kg) |
| Sabbath Mode | Yes |
| Door Swing | Drawer |
| Level Legs Qty | 4 |
