Summit All-Freezer, ADA Compliant, 24" Wide, White (VT65MLPLUS2)
SKU: VT65MLPLUS2
Dimensions: 33.5 H x 23.63 W x 23.5 D
About This Product
The Summit VT65MLPLUS2 is a 24" wide all-freezer, ADA compliant. It is designed for medical, pharmacy and clinical storage where stable temperatures matter. The cabinet measures 33.5 in. H x 23.63 in. W x 23.5 in. D, offers 3.2 cu.ft. of capacity and uses manual defrost.
It has a white cabinet finish. It operates on 115 V AC/60 Hz and draws 1.3 amps. It meets ADA height requirements for accessible installations. A lock helps keep the contents secure. It is backed by a 1-year manufacturer parts and labor warranty.
Planning a multi-unit project? Request a quote and our team will confirm pricing, availability and freight to your site.
Key Features
- Slim counter height dimensions
- -25ºC capable
- NIST calibrated temperature display
- Buffered temperature probe
- Factory installed lock
- Manual defrost
- Pull-out drawers
- Adjustable thermostat
- Matching refrigerator available
- Magnetic door gasket
- Foamed-in-place cabinet
- Approved for use in the USA and Canada
Specs & Details
Dimensions: 33.5 H x 23.63 W x 23.5 D
OVERVIEW
| Brand | Summit |
| Model | VT65MLPLUS2 |
| Category | Medical & Pharmacy Refrigerators |
DIMENSIONS
| Nominal Height | 34.0" (86 cm) |
| Height of Cabinet | 33.5" (85 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.63" (60 cm) |
| Nominal Depth | 24.0" (61 cm) |
| Depth | 23.5" (60 cm) |
| Depth with Handle | 25.13" (64 cm) |
| Depth with door at 90° | 46.13" (117 cm) |
| Interior Height | 24.25" (62 cm) |
| Interior Width | 17.75" (45 cm) |
| Interior Depth | 16.5" (42 cm) |
| Compressor Step Height | 6.5" (17 cm) |
| Compressor Step Width | 17.5" (44 cm) |
| Compressor Step Depth | 5.5" (14 cm) |
CAPACITY & STORAGE
| Capacity | 3.2 cu.ft. (91 L) |
| Cabinet | White |
| Interior Drawers | Yes |
| Drawers Qty | 3 |
ELECTRICAL
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.3 |
| Voltage/Frequency | 115 V AC/60 Hz |
COOLING & PERFORMANCE
| Defrost Type | Manual |
| Compressor Warranty | 5 Years |
| Thermostat Type | Dial |
| Refrigerant Type | R134a |
| Refrigerant Amount | 2.7 oz. |
| High Side PSI | 235.0 |
| Low Side PSI | 70.0 |
| Temperature Range | -12ºC to -25ºC |
CERTIFICATIONS & WARRANTY
| Parts & Labor Warranty | 1 Year |
FEATURES & FINISH
| Door | White |
| Weight | 105.0 lbs. (48 kg) |
| Door Swing | RHD |
| Reversible | Factory Reversible |
| Level Legs | 2 |
