Summit Built-In All-Freezer, ADA Compliant (Panel Not Included), 21" Wide, Black (ALFZ37BIF)
SKU: ALFZ37BIF
Dimensions: 31.75 H x 20.25 W x 23 D
About This Product
The Summit ALFZ37BIF is a 21" wide built-in all-freezer, ADA compliant (Panel not Included). It is sized for ADA-height counters so frozen storage stays within reach. The cabinet measures 31.75 in. H x 20.25 in. W x 23 in. D, offers 2.68 cu.ft. of capacity and uses manual defrost.
The black cabinet is paired with a panel-ready door. It operates on 115 V AC/60 Hz and draws 0.6 amps. It meets ADA height requirements for accessible installations. The door accepts a custom panel (sold separately) for a seamless built-in look. It is backed by a 1-year manufacturer parts and labor warranty.
Planning a multi-unit project? Request a quote and our team will confirm pricing, availability and freight to your site.
Key Features
- ADA compliant design
- Built-in capable
- Panel-ready door
- Adjustable thermostat
- Door shelves
- Adjustable shelves
- 3" thick door
- Temperature alarms
- Open door alarm
- Sealed back
- Right-angle plug
- Manual defrost
Specs & Details
Dimensions: 31.75 H x 20.25 W x 23 D
OVERVIEW
| Brand | Summit |
| Model | ALFZ37BIF |
| Category | ADA Compliant Freezers |
DIMENSIONS
| Nominal Height | 32.0" (81 cm) |
| Height of Cabinet | 31.75" (81 cm) |
| Height to Hinge Cap | 32.0" (81 cm) |
| Nominal Width | 21.0" (53 cm) |
| Width | 20.25" (51 cm) |
| Nominal Depth | 23.0" (58 cm) |
| Depth | 23.0" (58 cm) |
| Depth with Handle | 24.38" (62 cm) |
| Depth with door at 90° | 40.25" (102 cm) |
| Interior Height | 23.75" (60 cm) |
| Interior Width | 14.5" (37 cm) |
| Interior Depth | 17.0" (43 cm) |
| Compressor Step Height | 5.75" (15 cm) |
| Compressor Step Width | 14.5" (37 cm) |
| Compressor Step Depth | 6.0" (15 cm) |
CAPACITY & STORAGE
| Capacity | 2.68 cu.ft. (76 L) |
| Cabinet | Black |
| Shelf Type | Wire |
| Shelf Qty | 3 |
| Full Door Shelves | 3 |
| Adjustable Shelves | Yes |
ELECTRICAL
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Energy Usage/Year | 266.0kWh/year |
| Amps | 0.6 |
| Voltage/Frequency | 115 V AC/60 Hz |
COOLING & PERFORMANCE
| Defrost Type | Manual |
| Compressor Warranty | 5 Years |
| Thermostat Type | Digital |
| Fan Type | Exterior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 1.83 oz. |
| High Side PSI | 180.0 |
| Low Side PSI | 80.0 |
| Temperature Range | -13 to 5ºF |
| Sound Level | 33.1 dBa |
CERTIFICATIONS & WARRANTY
| Parts & Labor Warranty | 1 Year |
FEATURES & FINISH
| Door | Panel-Ready |
| Weight | 75.0 lbs. (34 kg) |
| Door Swing | RHD |
| Reversible | Factory Reversible |
| Level Legs | 2 |
| Wheels | 2 |
