About This Product

The Summit ALFZ53IM is a 24" wide built-in all-freezer with icemaker, ADA compliant. It is sized for ADA-height counters so frozen storage stays within reach. The cabinet measures 32 in. H x 23.38 in. W x 22.88 in. D, offers 3.7 cu.ft. of capacity and uses frost-free defrost.

The black cabinet is paired with a stainless steel door. It operates on 115 V AC/60 Hz and draws 1.5 amps. It meets ADA height requirements for accessible installations. A lock helps keep the contents secure. It is backed by a 1-year manufacturer parts and labor warranty.

Planning a multi-unit project? Request a quote and our team will confirm pricing, availability and freight to your site.

Key Features

Factory-installed icemaker
ADA compliant design
Built-in capable
Frost-free operation
Stainless steel door
Digital thermostat
Recessed LED light
Reversible door
Adjustable shelves
Factory installed lock
Professional handle
Open door alarm

Specs & Details

Dimensions: 32 H x 23.38 W x 22.88 D

OVERVIEW

Brand	Summit
Model	ALFZ53IM
Category	ADA Compliant Freezers

DIMENSIONS

Height of Cabinet	32.0" (81 cm)
Width	23.38" (59 cm)
Depth	22.88" (58 cm)
Depth with Handle	24.63" (63 cm)
Depth with door at 90°	46.88" (119 cm)
Interior Height	23.5" (60 cm)
Interior Width	18.63" (47 cm)
Interior Depth	15.5" (39 cm)
Compressor Step Height	5.0" (13 cm)
Compressor Step Width	18.63" (47 cm)
Compressor Step Depth	4.5" (11 cm)

CAPACITY & STORAGE

Capacity	3.7 cu.ft. (105 L)
Cabinet	Black
Shelf Type	Chrome
Shelf Qty	3
Adjustable Shelves	Yes
Interior Light	Yes

ELECTRICAL

US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Energy Usage/Year	345.0kWh/year
Amps	1.5
Plug Type	NEMA 5-15P (Right Angle)
Voltage/Frequency	115 V AC/60 Hz

COOLING & PERFORMANCE

Defrost Type	Frost-Free
Compressor Warranty	5 Years
Thermostat Type	Digital
Fan Type	Interior and Exterior
Refrigerant Type	R600a
Refrigerant Amount	1.31 oz.
High Side PSI	270.0
Low Side PSI	105.0
Temperature Range	-11°F to 11°F
