Summit Compact All-Freezer, White (FS30L7NZ)

SKU: FS30L7NZ

Dimensions: 27 H x 18.5 W x 17.75 D

About This Product

The Summit FS30L7NZ is a compact all-freezer. It is designed for medical, pharmacy and clinical storage where stable temperatures matter. The cabinet measures 27 in. H x 18.5 in. W x 17.75 in. D, offers 1.8 cu.ft. of capacity and uses manual defrost.

It has a white cabinet finish. It operates on 115 V AC/60 Hz and draws 0.8 amps. A lock helps keep the contents secure. It is backed by a 1-year manufacturer parts and labor warranty.

Planning a multi-unit project? Request a quote and our team will confirm pricing, availability and freight to your site.

Key Features

Commercially approved
NIST calibrated temperature display
High/low temperature alarm
Compact dimensions
Versatile display
Manual defrost
Adjustable thermostat
Factory installed lock
Reversible door
Removable shelves
Flat door liner
One piece interior liner

Specs & Details

Dimensions: 27 H x 18.5 W x 17.75 D

OVERVIEW

Brand	Summit
Model	FS30L7NZ
Category	Medical & Pharmacy Refrigerators

DIMENSIONS

Nominal Height	27.0" (69 cm)
Height of Cabinet	27.0" (69 cm)
Height to Hinge Cap	24.63" (63 cm)
Nominal Width	19.0" (48 cm)
Width	18.5" (47 cm)
Nominal Depth	18.0" (46 cm)
Depth	17.75" (45 cm)
Depth with door at 90°	34.5" (88 cm)
Interior Height	18.63" (47 cm)
Interior Width	13.38" (34 cm)
Interior Depth	13.0" (33 cm)
Compressor Step Height	8.0" (20 cm)
Compressor Step Width	13.38" (34 cm)
Compressor Step Depth	5.75" (15 cm)

CAPACITY & STORAGE

Capacity	1.8 cu.ft. (51 L)
Cabinet	White
Shelf Type	Wire
Shelf Qty	2

ELECTRICAL

US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Amps	0.8
Voltage/Frequency	115 V AC/60 Hz

COOLING & PERFORMANCE

Defrost Type	Manual
Compressor Warranty	5 Years
Thermostat Type	Dial
Refrigerant Type	R600a
Refrigerant Amount	0.8 oz.

CERTIFICATIONS & WARRANTY

Sanitation	ETL-S
Parts & Labor Warranty	1 Year

FEATURES & FINISH

Door	White
Weight	43.0 lbs. (20 kg)
Door Swing	RHD
Reversible	Yes
Level Legs	2
